Le format SVG

Le SVG est un format d’images vectorielles basé sur le XML, créé par le W3C en 2001. Contrairement aux images matricielles (comme JPEG ou PNG) qui sont composées de pixels, les images SVG sont construites à partir de formes géométriques définies mathématiquement.

Commençons par comprendre les caractéristiques fondamentales du SVG :

Le concept de vectoriel signifie que l’image est définie par des équations mathématiques plutôt que par une grille de pixels. Imaginez que vous dessinez un cercle : au lieu de colorier des pixels un par un, vous définissez simplement un centre et un rayon. Cette approche mathématique permet au SVG d’être redimensionné sans perte de qualité, d’où le terme « Scalable » dans son nom.

Voici un exemple simple de code SVG pour dessiner un cercle :

<svg width="200" height="200">
  <circle cx="100" cy="100" r="50" fill="red"/>
</svg>

Dans cet exemple, chaque attribut a une signification précise :

• cx et cy définissent les coordonnées du centre du cercle
• r définit le rayon
• fill détermine la couleur de remplissage

Les SVG supportent plusieurs formes géométriques de base :

Les rectangles :

<rect x="10" y="10" width="100" height="50"/>

Les lignes :

<line x1="0" y1="0" x2="100" y2="100"/>

Les chemins complexes (paths) qui permettent de créer des formes sophistiquées :

<path d="M 10 10 L 90 90 Z"/>

Un avantage majeur du SVG est sa capacité à être stylisé via CSS et manipulé via JavaScript, ce qui le rend particulièrement adapté au web moderne. Par exemple, vous pouvez animer un élément SVG :

<svg width="200" height="200">
  <circle cx="100" cy="100" r="50" fill="blue">
    <animate attributeName="r" values="50;80;50" dur="2s" repeatCount="indefinite"/>
  </circle>
</svg>

Les cas d’utilisation courants du SVG incluent :

• Les logos et icônes qui doivent s’adapter à différentes tailles d’écran
• Les graphiques et visualisations de données
• Les animations web légères
• Les illustrations techniques nécessitant une grande précision

Pour illustrer concrètement, créons ensemble un exemple plus complexe :

Cette démonstration illustre plusieurs concepts clés du SVG :

Le système de coordonnées : Le SVG utilise un système où (0,0) est situé dans le coin supérieur gauche. Les valeurs de x augmentent vers la droite et les valeurs de y vers le bas.

La superposition des éléments : Les éléments SVG sont rendus dans l’ordre où ils apparaissent dans le code. Les derniers éléments sont dessinés par-dessus les précédents.

Les attributs de style : Nous pouvons contrôler l’apparence avec des attributs comme fill (couleur de remplissage), stroke (couleur de bordure), opacity (transparence), etc.

La composition : On peut combiner des formes simples pour créer des illustrations complexes. Dans notre exemple, nous avons utilisé un cercle, un rectangle et un triangle (polygon) pour créer une composition simple.

Pour conclure, le format SVG est particulièrement puissant pour :

• Créer des images qui s’adaptent parfaitement à toutes les tailles d’écran
• Réduire la taille des fichiers pour les graphiques simples
• Permettre l’animation et l’interactivité
• Maintenir une qualité optimale quel que soit le zoom

Les animations SVG peuvent être créées de deux manières principales : soit directement dans le SVG avec les éléments d’animation SMIL (Synchronized Multimedia Integration Language), soit via CSS/JavaScript. Commençons par les animations natives SMIL car elles forment la base de la compréhension.

Voici un exemple concret qui va nous permettre d’explorer plusieurs types d’animations :

Dans cet exemple, j’ai intégré quatre types différents d’animations couramment utilisées. Analysons chacune d’entre elles :

• L’animation de taille (le cercle bleu) :
  Cette animation utilise l’élément <animate> pour modifier l’attribut « r » (rayon) du cercle. La syntaxe values= »20;30;20″ crée une animation fluide qui fait grandir puis rétrécir le cercle. C’est un excellent exemple d’animation d’attribut simple.
• L’animation de rotation (le carré vert) :
  Cette animation utilise <animateTransform> qui est spécialement conçu pour les transformations géométriques. Le type= »rotate » fait tourner le rectangle autour d’un point central défini. C’est plus complexe car elle implique une transformation matricielle sous-jacente.
• L’animation de couleur (l’étoile rouge) :
  Cette animation montre comment on peut animer les propriétés de style comme la couleur. L’interpolation des couleurs est gérée automatiquement par le navigateur, créant une transition fluide entre les différentes teintes.
• L’animation de tracé (la ligne violette ondulée) :
  Cette animation utilise stroke-dasharray pour créer un effet de dessin progressif. C’est une technique plus avancée qui joue sur les propriétés de contour pour créer une illusion de mouvement.

Les attributs communs à toutes ces animations sont :

• dur : la durée de l’animation
• repeatCount : le nombre de répétitions (indefinite pour une boucle infinie)
• values ou from/to : les valeurs de début et de fin de l’animation

Il existe également des moyens plus avancés d’animer les SVG, comme :

Les animations basées sur CSS :

@keyframes rotation {
    from { transform: rotate(0deg); }
    to { transform: rotate(360deg); }
}

.element-anime {
    animation: rotation 2s linear infinite;
}

Les animations JavaScript qui offrent un contrôle plus précis :

element.animate([
    { transform: 'scale(1)' },
    { transform: 'scale(1.5)' },
    { transform: 'scale(1)' }
], {
    duration: 2000,
    iterations: Infinity
});

L’avantage des animations SVG est leur légèreté et leur fluidité.
Comme elles sont vectorielles, elles restent nettes quel que soit le niveau de zoom ou la taille de l’écran. De plus, elles peuvent être contrôlées par JavaScript, ce qui permet de créer des interactions sophistiquées.

TUX en SVG :

Le code source de l’image SVG

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE svg PUBLIC "-//W3C//DTD SVG 1.1//EN" "http://www.w3.org/Graphics/SVG/1.1/DTD/svg11.dtd">
<svg width="500pt" height="600pt" xmlns="http://www.w3.org/2000/svg" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:rdf="http://www.w3.org/1999/02/22-rdf-syntax-ns#" xmlns:dc="http://purl.org/dc/elements/1.1/" xmlns:cc="http://web.resource.org/cc/">

<defs>

<linearGradient id="linearGradient172">

<stop style="stop-color:#3f2600;stop-opacity:0.6;" offset="0" id="stop173"/>

<stop style="stop-color:#3f2600;stop-opacity:0;" offset="1" id="stop174"/>
</linearGradient>
      <linearGradient id="linearGradient167">

<stop style="stop-color:#ffffff;stop-opacity:0.65;" offset="0" id="stop168"/>

<stop style="stop-color:#ffffff;stop-opacity:0;" offset="1" id="stop169"/>
</linearGradient>
      <linearGradient id="linearGradient162">

<stop style="stop-color:#ffa63f;stop-opacity:1;" offset="0" id="stop163"/>

<stop style="stop-color:#ffff00;stop-opacity:1;" offset="1" id="stop164"/>
</linearGradient>
      <linearGradient id="linearGradient153">

<stop style="stop-color:#ffeed7;stop-opacity:1;" offset="0" id="stop154"/>

<stop style="stop-color:#bdbfc2;stop-opacity:1;" offset="1" id="stop155"/></linearGradient>

<linearGradient id="linearGradient138">

<stop style="stop-color:#ffffff;stop-opacity:0.8;" offset="0" id="stop139"/>

<stop style="stop-color:#ffffff;stop-opacity:0;" offset="1" id="stop140"/>
</linearGradient>
      <linearGradient xlink:href="#linearGradient138" id="linearGradient141" x1="0.47424799" y1="0.020191999" x2="0.417539" y2="0.90125799" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient142" x1="0.55880702" y1="0.031192999" x2="0.553922" y2="0.94531101" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient143" x1="0.46557701" y1="0.028819799" x2="0.41365999" y2="0.93366498" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient144" x1="0.70346397" y1="0.059404202" x2="0.64553201" y2="0.94063401" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient145" x1="0.46741399" y1="-0.036155298" x2="0.86741799" y2="0.75857902" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient146" x1="0.57152498" y1="0.023441499" x2="0.57143003" y2="0.71875" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient147" x1="0.5" y1="0.0234362" x2="0.5" y2="0.8125" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient148" x1="0.50799799" y1="0.37435901" x2="0.51599997" y2="0.92820501" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient138" id="linearGradient149" x1="0.5" y1="0.131707" x2="0.50400001" y2="0.94634098" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient150" x1="-0.30509499" y1="0.099496603" x2="0.156323" y2="0.94191301" gradientUnits="objectBoundingBox" gradientTransform="matrix(-0.928523,0.283938,0.435332,0.943857,-1.91327e-7,5.49908e-8)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient151" x1="0.433979" y1="0.022184599" x2="0.487055" y2="1.02569" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient152" x1="0.5" y1="0.89842999" x2="0.5" y2="0.40625" gradientUnits="objectBoundingBox" spreadMethod="reflect"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient156" x1="0.43568701" y1="0.98882002" x2="0.453989" y2="0.23093501" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient157" x1="0.49180499" y1="1.15284" x2="0.49482101" y2="0.41252401" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient158" x1="0.51730198" y1="0.85418499" x2="0.49843901" y2="0.136172" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient159" x1="0.46201" y1="0.87917101" x2="0.49215299" y2="0.096282303" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient161" x1="0.50086302" y1="0.34872901" x2="0.41209599" y2="0.98558098" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient165" x1="0.60399801" y1="0.51020199" x2="0.46399999" y2="0.98367399" gradientUnits="objectBoundingBox"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient166" x1="0.50000501" y1="0.191616" x2="0.50800002" y2="0.97005898" gradientUnits="objectBoundingBox"/>

<radialGradient xlink:href="#linearGradient172" id="radialGradient171" cx="0.5" cy="0.5" fx="0.5" fy="0.5" r="0.5" gradientUnits="objectBoundingBox"/>

<radialGradient xlink:href="#linearGradient172" id="radialGradient176"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient178" x1="0.94027299" y1="1.2934099" x2="0.19452" y2="-0.675295" gradientUnits="objectBoundingBox"/>

<radialGradient xlink:href="#linearGradient172" id="radialGradient1399" gradientTransform="scale(1.045233,0.956725)" cx="446.77762" cy="1219.4125" fx="446.77762" fy="1219.4125" r="195.07191" gradientUnits="userSpaceOnUse"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1401" gradientUnits="userSpaceOnUse" x1="400.57785" y1="369.53015" x2="400.84448" y2="304.07886" gradientTransform="scale(0.575262,1.738339)"/>

<linearGradient xlink:href="#linearGradient138" id="linearGradient1403" gradientUnits="userSpaceOnUse" x1="303.01761" y1="237.93179" x2="297.0856" y2="330.09561" gradientTransform="scale(1.116071,0.896001)"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1405" gradientUnits="userSpaceOnUse" gradientTransform="scale(0.816497,1.224744)" x1="378.93771" y1="278.60202" x2="380.27319" y2="243.91606"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1407" gradientUnits="userSpaceOnUse" x1="381.38742" y1="277.495" x2="380.5517" y2="245.68338" gradientTransform="scale(0.816497,1.224744)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1409" gradientUnits="userSpaceOnUse" gradientTransform="scale(0.816497,1.224744)" x1="379.09573" y1="240.92712" x2="376.79556" y2="281.01636"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1411" gradientUnits="userSpaceOnUse" x1="389.63535" y1="242.28218" x2="387.06866" y2="281.32513" gradientTransform="scale(0.816497,1.224744)"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1413" gradientUnits="userSpaceOnUse" spreadMethod="reflect" x1="437.57941" y1="528.87177" x2="437.57941" y2="394.10361" gradientTransform="scale(0.812855,1.230232)"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1415" gradientUnits="userSpaceOnUse" x1="375.17325" y1="419.78485" x2="377.48541" y2="324.03815" gradientTransform="scale(0.649784,1.538974)"/>

<linearGradient xlink:href="#linearGradient138" id="linearGradient1417" gradientUnits="userSpaceOnUse" x1="320.75104" y1="498.17776" x2="321.32224" y2="614.50439" gradientTransform="scale(1.074798,0.930408)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1419" gradientUnits="userSpaceOnUse" x1="322.48257" y1="435.26761" x2="323.2514" y2="488.48251" gradientTransform="scale(1.077001,0.928504)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1421" gradientUnits="userSpaceOnUse" x1="411.2215" y1="242.94365" x2="411.2215" y2="331.44858" gradientTransform="scale(0.571707,1.749147)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1423" gradientUnits="userSpaceOnUse" x1="867.34546" y1="234.73897" x2="867.33453" y2="314.83911" gradientTransform="scale(0.572667,1.746214)"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient1425" gradientUnits="userSpaceOnUse" x1="236.25362" y1="657.11133" x2="212.5099" y2="737.41229" gradientTransform="scale(1.011514,0.988617)"/>

<linearGradient xlink:href="#linearGradient153" id="linearGradient1427" gradientUnits="userSpaceOnUse" x1="381.56607" y1="655.73102" x2="279.64313" y2="386.66583" gradientTransform="scale(1.065499,0.938527)"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient1429" gradientUnits="userSpaceOnUse" x1="218.11714" y1="630.30475" x2="203.12654" y2="737.8537" gradientTransform="scale(1.009851,0.990245)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1431" gradientUnits="userSpaceOnUse" gradientTransform="scale(1.007724,0.992335)" x1="117.88966" y1="587.23602" x2="182.24524" y2="704.73077"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1433" gradientUnits="userSpaceOnUse" x1="223.10072" y1="570.41809" x2="230.53499" y2="710.97723" gradientTransform="scale(0.999504,1.000496)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1435" gradientUnits="userSpaceOnUse" x1="316.93988" y1="474.01779" x2="371.60889" y2="582.63507" gradientTransform="scale(1.065499,0.938527)"/>

<linearGradient xlink:href="#linearGradient162" id="linearGradient1437" gradientUnits="userSpaceOnUse" x1="284.68652" y1="410.46326" x2="285.45923" y2="485.69934" gradientTransform="scale(1.218684,0.820557)"/>

<linearGradient xlink:href="#linearGradient167" id="linearGradient1439" gradientUnits="userSpaceOnUse" x1="288.82358" y1="398.85422" x2="288.37628" y2="482.55939" gradientTransform="scale(1.221941,0.81837)"/>
</defs>

<g id="g1369" transform="translate(-310.7524,-64.25268)">

<path transform="matrix(1.4177,0,0,0.414745,-38.7944,222.194)" d="M 670.88202 1166.6423 A 203.89551 186.63016 0 1 1 263.091,1166.6423 A 203.89551 186.63016 0 1 1 670.88202 1166.6423 z" id="path175" style="fill:url(#radialGradient1399);stroke:none;stroke-width:1pt;stroke-linecap:butt;stroke-linejoin:miter"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path106" d="M 223.627,632.24 C 201.239,600.017 196.873,495.256 249.114,430.81 C 275,399.892 281.604,378.345 283.645,349.417 C 285.034,316.438 260.32,217.975 353.528,210.473 C 447.934,202.941 442.864,296.133 442.321,345.448 C 441.87,387.088 472.895,410.689 494.117,443.143 C 533.396,502.773 530.074,605.443 486.718,661.015 C 431.801,730.583 384.765,700.413 353.528,702.945 C 295.035,706.147 293.101,737.336 223.627,632.24 z " style="fill:#000000;stroke:none;stroke-width:1.25;"/>

<path transform="matrix(-1.67739,-2.24516e-2,-2.11236e-2,1.4709,1173.58,-293.017)" id="path113" d="M 246.571,470.864 C 234.332,483.36 202.175,539.956 251.44,576.224 C 268.809,588.857 235.063,635.719 219.435,612.532 C 191.865,570.914 210.604,505.591 227.75,482.344 C 239.402,465.857 256.98,459.668 246.571,470.864 z " style="fill:url(#linearGradient1401);stroke:none;stroke-width:0.99464899;"/>

<path transform="matrix(-1.67755,0,0,1.52374,1174.62,-318.082)" id="path111" d="M 256.513,459.837 C 236.598,477.554 200.337,539.928 253.225,580.443 C 270.595,593.075 237.832,632.906 219.435,612.532 C 155.472,541.712 221.104,460.278 243.697,432.282 C 263.889,407.935 281.775,438.034 256.513,459.837 z " style="fill:#000000;stroke:#000000;stroke-width:0.97729802;"/>

<path transform="matrix(1.26626,-7.13667e-2,-4.59795e-2,1.19574,202.143,-125.761)" d="M 399.56879 258.15753 A 58.37323 46.863022 0 1 1 282.82233,258.15753 A 58.37323 46.863022 0 1 1 399.56879 258.15753 z" id="path114" style="fill:url(#linearGradient1403);stroke:none;stroke-width:1.26498997;"/>

<path transform="matrix(1.30445,-7.55326e-2,7.71251e-2,1.34257,144.757,-177.617)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path115" style="fill:url(#linearGradient1405);stroke:none;stroke-width:1.17873001;"/>

<path transform="matrix(-1.81082,4.95107e-2,3.17324e-2,1.55333,1207.46,-284.777)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path116" style="fill:url(#linearGradient1407);stroke:none;stroke-width:0.93138498;"/>

<path transform="matrix(-0.823196,-1.76123e-3,-1.82321e-2,0.852662,913.674,-37.9902)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path117" style="fill:#000000;stroke:none;stroke-width:1.86495996;"/>

<path transform="matrix(0.59438,-7.22959e-2,6.88176e-2,0.705838,367.448,32.4186)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path118" style="fill:#000000;stroke:none;stroke-width:2.39814997;"/>

<path transform="matrix(-0.480323,-3.6454e-2,-4.67935e-2,0.475606,813.496,87.0124)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path121" style="fill:url(#linearGradient1409);stroke:none;stroke-width:3.1916101;"/>

<path transform="matrix(0.35691,-4.08211e-2,4.13232e-2,0.398544,449.334,114.991)" d="M 328.86324 320.64151 A 18.087479 27.131195 0 1 1 292.68828,320.64151 A 18.087479 27.131195 0 1 1 328.86324 320.64151 z" id="path122" style="fill:url(#linearGradient1411);stroke:none;stroke-width:4.12025976;"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-168.23)" id="path128" d="M 258.702,495.425 C 271.538,466.322 298.816,415.199 299.397,375.667 C 299.397,344.225 393.576,336.716 401.134,368.109 C 408.692,399.502 427.875,446.592 440.084,469.265 C 452.292,491.937 487.893,563.96 449.968,626.811 C 415.811,682.455 312.243,726.477 256.958,619.254 C 238.355,582.047 241.673,535.939 258.702,495.425 z " style="fill:url(#linearGradient1413);stroke:none;stroke-width:1.25;"/>

<path transform="matrix(1.38936,-0.111074,0.102211,1.30214,108.413,-165.938)" id="path112" d="M 242.905,473.815 C 231.642,492.782 207.405,543.124 255.042,575.862 C 306.353,610.682 301.515,672.924 239.435,637.817 C 182.658,606.028 216.59,500.039 234.925,475.551 C 247.032,458.337 264.822,437.52 242.905,473.815 z " style="fill:url(#linearGradient1415);stroke:none;stroke-width:1.15804005;"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path109" d="M 256.513,449.72 C 239.048,478.228 197.136,545.533 253.225,580.443 C 328.794,626.798 307.398,673.154 238.426,631.417 C 141.317,573.153 226.601,455.801 265.557,411.079 C 310.001,360.879 274.111,420.166 256.513,449.72 z " style="fill:#000000;stroke:#000000;stroke-width:1.25;"/>

<path id="path125" d="M 421.481,504.727 C 421.481,537.139 392.209,579.243 341.953,578.865 C 290.125,579.32 268.004,537.139 268.004,504.727 C 268.004,472.315 302.383,446.01 344.743,446.01 C 387.102,446.01 421.481,472.315 421.481,504.727 z " style="font-size:12px;fill:url(#linearGradient1417);stroke:none;stroke-width:1.23705006;stroke-dasharray:none" transform="matrix(1.30209,0,0,1.22525,170.042,-153.557)"/>

<path id="path127" d="M 398.227,412.292 C 397.615,450.864 375.047,459.963 346.487,459.963 C 317.926,459.963 297.195,454.269 294.746,412.292 C 294.746,385.978 317.926,370.75 346.487,370.75 C 375.047,370.75 398.227,385.978 398.227,412.292 z " style="font-size:12px;fill:url(#linearGradient1419);stroke:none;stroke-width:1.38846004;stroke-dasharray:none" transform="matrix(1.1868,0,0,1.06708,210.623,-100.078)"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path129" d="M 234.285,456.475 C 252.001,429.479 289.3,388.111 241.262,462.288 C 202.311,523.331 226.859,562.561 239.518,573.327 C 276.045,605.889 274.484,627.676 245.913,610.533 C 184.288,573.907 197.078,512.285 234.285,456.475 z " style="fill:url(#linearGradient1421);stroke:none;stroke-width:1.25;"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path131" d="M 490.662,467.52 C 475.343,435.819 426.528,355.618 492.988,448.917 C 553.449,533.214 511.01,591.93 503.452,597.744 C 495.895,603.557 470.315,615.184 477.873,594.837 C 485.43,574.49 523.107,535.864 490.662,467.52 z " style="fill:url(#linearGradient1423);stroke:none;stroke-width:1.25;"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path132" d="M 220.915,716.921 C 180.473,695.505 121.663,721.045 143.013,662.855 C 147.289,649.617 136.638,629.847 143.594,616.929 C 151.733,601.231 169.174,604.72 179.639,594.255 C 189.957,583.364 196.498,564.606 215.683,567.513 C 234.867,570.42 247.628,593.974 261.027,622.742 C 270.91,643.38 305.968,672.406 303.677,695.5 C 300.981,731 260.65,737.69 220.915,716.921 z " style="fill:url(#linearGradient1425);stroke:#e68c3f;stroke-width:6.25;"/>

<path id="path177" d="M 415.072,495.764 C 412.065,520.67 379.259,572.391 345.554,577.298 C 311.294,582.634 279.122,543.238 271.407,506.184 C 261.518,464.978 293.994,448.584 343.345,449.557 C 396.646,451.211 417.466,463.448 415.072,495.764 z " style="font-size:12px;fill:url(#linearGradient1427);stroke:none;stroke-width:2.85509992;stroke-dasharray:none" transform="matrix(0.598206,0.268584,-0.239623,0.617213,700.568,140.464)"/>

<path transform="matrix(-1.1685,0.423145,0.475283,1.16478,728.343,-213.821)" id="path133" d="M 220.274,718.402 C 178.947,694.812 120.38,724.007 143.013,662.855 C 147.749,649.787 136.417,629.303 143.373,616.385 C 151.512,600.687 169.174,604.72 179.639,594.255 C 189.957,583.364 198.466,566.387 217.651,569.294 C 236.835,572.201 247.628,593.974 261.027,622.742 C 270.91,643.38 304.442,671.713 302.151,694.807 C 299.455,730.307 259.427,740.278 220.274,718.402 z " style="fill:url(#linearGradient1429);stroke:#e68c3f;stroke-width:6.25067997;"/>

<path transform="matrix(-0.945096,0.343745,0.424076,0.956058,714.328,-64.342)" id="path134" d="M 216.482,675.68 C 129.951,618.177 169.174,604.72 179.639,594.255 C 189.957,583.364 198.466,566.387 217.651,569.294 C 236.835,572.201 247.628,593.974 261.027,622.742 C 270.91,643.38 304.087,671.66 302.151,694.807 C 299.535,721.917 253.961,700.294 216.482,675.68 z " style="fill:url(#linearGradient1431);stroke:none;stroke-width:1.52532005;"/>

<path transform="matrix(1.00431,-5.2286e-2,-1.74e-2,1.04575,244.191,-28.4653)" id="path135" d="M 216.506,677.071 C 129.975,619.568 169.709,603.501 182.56,595.791 C 197.959,585.849 197.718,564.96 216.903,567.867 C 236.087,570.774 247.628,593.974 261.027,622.742 C 270.91,643.38 304.087,671.66 302.151,694.807 C 299.535,721.917 253.985,701.685 216.506,677.071 z " style="fill:url(#linearGradient1433);stroke:none;stroke-width:1.52532005;"/>

<path id="path136" d="M 415.072,495.764 C 412.065,520.67 379.259,572.391 345.554,577.298 C 311.294,582.634 279.122,543.238 271.407,506.184 C 261.518,464.978 293.994,448.584 343.345,449.557 C 396.646,451.211 417.466,463.448 415.072,495.764 z " style="font-size:12px;fill:#000000;stroke:none;stroke-width:2.85509992;" transform="matrix(0.515584,0.215259,-0.206526,0.49467,713.3,222.559)"/>

<path id="path137" d="M 415.072,495.764 C 412.065,520.67 379.259,572.391 345.554,577.298 C 311.294,582.634 279.122,543.238 271.407,506.184 C 261.518,464.978 293.994,448.584 343.345,449.557 C 396.646,451.211 417.466,463.448 415.072,495.764 z " style="font-size:12px;fill:url(#linearGradient1435);stroke:none;stroke-width:2.85509992;" transform="matrix(0.351231,0.149463,-0.128856,0.343469,724.522,318.291)"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path119" d="M 309.954,338.729 C 317.101,331.959 334.765,311.663 367.915,332.974 C 374.077,336.984 379.077,337.351 390.936,342.429 C 414.662,352.178 403.318,375.688 378.192,383.537 C 367.434,387.026 357.656,400.093 338.063,398.976 C 321.329,397.999 316.944,387.102 306.665,381.07 C 288.396,370.759 285.7,356.816 295.565,349.417 C 305.431,342.018 309.29,339.358 309.954,338.729 z " style="fill:url(#linearGradient1437);stroke:#e68c3f;stroke-width:3.75;"/>

<path transform="matrix(1.25,0,0,1.25,185.454,-167.505)" id="path120" d="M 391.251,357.645 C 381.368,358.226 359.858,379.736 337.185,379.736 C 314.512,379.736 301.141,358.807 297.653,358.807" style="fill:none;stroke:#e68c3f;stroke-width:2.5;"/>

<path transform="matrix(0.627885,0,0,0.595666,392.366,51.8173)" id="path123" d="M 309.954,338.729 C 317.101,331.959 339.645,313.381 369.542,332.401 C 375.841,336.167 382.346,340.266 392.02,345.865 C 411.182,357.613 401.691,374.543 378.734,385.255 C 368.316,389.75 351.141,399.67 338.063,398.976 C 323.53,397.568 314.128,387.577 304.496,381.07 C 286.826,368.767 287.899,358.833 296.107,350.562 C 302.312,344.883 309.29,339.358 309.954,338.729 z " style="fill:url(#linearGradient1439);stroke:none;"/>
</g>
</svg>
